Friction hinges
The friction torque is adjustable with a hex key.
Available with a choice of studs or holes.
3 other versions available: with spring, with detent function or free swinging.
Large friction hinges - adjustable
Large size friction hinge to maintain a lid / door in position.The friction torque is adjustable with a hex key.
Available with a choice of studs or holes.
3 other versions available: with spring, with detent function or free swinging.
NS
Non-stock items available to order
Axial load | Radial load | Load with 90° angle | |
---|---|---|---|
Tensile tests | |||
References | Maximum load (N) | Maximum load (N) | Maximum load (N) |
72-1-4145 | 8070 | 8960 | 4860 |
72-1-4146 | 8070 | 8960 | 4860 |
72-1-4147 | 8070 | 8960 | 4860 |
72-1-4148 | 8070 | 8960 | 4860 |
72-1-4362 | 8070 | 8960 | 4860 |
72-1-4365 | 8070 | 8960 | 4860 |
72-1-4363 | 8070 | 8960 | 4860 |
72-1-4364 | 8070 | 8960 | 4860 |
The values stated are derived from the tests carried out by PINET according to the conditions mentioned in the link below.This does not replace in any way the calculations or validation tests that the customer must make on his application with the hinge.
Test conditions and protocols
