Hinges with lift-assist
The retaining torque is adjustable with a hex key (0 to 3.5 N.m).
Cycling resistance: 50,000 cycles.
Operating temperature: 0°/+40°C.
The hinge is delivered with a pin attached. It keeps the hinge open.
Please do not detach until the hinge is installed.
Optional cover is sold separately (22-7-3556).
Spring-assist torque hinge
The built-in spring makes lids feel lighter to open (the hinge is for top-opening lids).The retaining torque is adjustable with a hex key (0 to 3.5 N.m).
Cycling resistance: 50,000 cycles.
Operating temperature: 0°/+40°C.
The hinge is delivered with a pin attached. It keeps the hinge open.
Please do not detach until the hinge is installed.
Optional cover is sold separately (22-7-3556).
![Charnière à friction avec assistance à l'ouverture](https://www.pinet-industrie.com/images/cache/image_xxl/images/category/71-7-3910_71-7-3911_plan.jpg)
