Latching hinges
Allows you to open door as left- or right hinged door, or to remove door completely. Universal left- and right assembly.
Available with a built-in safety catch for safe opening of pressurized doors. In addition to the 3 mm compression that always applies, the latching hinge can easily be adjusted between offset 0 mm, 1.5 mm or 3 mm to put more pressure on the gasket and ensure a tight and sealed door.
Door part mounts on a mounting bracket (included) which stabilize the door in the latching hinge area and provide further adjustability.
The latching hinge can be adjusted 3 mm in all three directions. Insert: recessed hexagon 8 mm, with open and close indication for insert position.
Frame part mounts with screws. Mounting bracket for the door mounts with Ø 4 mm blind rivets.
Note that a normal panel will need four units in order to operate as either left-open, right open, or completely removable.
No problems with thermal break as units are surface-mounted on to door and frame parts, resulting in no parts intruding through the double skinned doors.
Compression latching hinges
Latching hinge that may be used as hinge or latch according to need.Allows you to open door as left- or right hinged door, or to remove door completely. Universal left- and right assembly.
Available with a built-in safety catch for safe opening of pressurized doors. In addition to the 3 mm compression that always applies, the latching hinge can easily be adjusted between offset 0 mm, 1.5 mm or 3 mm to put more pressure on the gasket and ensure a tight and sealed door.
Door part mounts on a mounting bracket (included) which stabilize the door in the latching hinge area and provide further adjustability.
The latching hinge can be adjusted 3 mm in all three directions. Insert: recessed hexagon 8 mm, with open and close indication for insert position.
Frame part mounts with screws. Mounting bracket for the door mounts with Ø 4 mm blind rivets.
Note that a normal panel will need four units in order to operate as either left-open, right open, or completely removable.
No problems with thermal break as units are surface-mounted on to door and frame parts, resulting in no parts intruding through the double skinned doors.
