Concealed hinges for surface mounted doors or nested doors
Pins in 430 stainless steel for 70-1-3639.
Pins in 304 Cu stainless steel for 70-1-3640.
Mounting features:
- For nested doors or surface mounted doors.
- LH or RH options.
- For horizontal or vertical applications.
Opening angle differs according to door thickness:
- 2 mm thickness: opening angle of 125°.
- 8 mm thickness: opening angle of 110°.
- 13 mm thickness: opening angle of 100°.
Please ask us for bespoke solutions.
Produced mainly in stainless steel, for a complete description of the materials contact us.
Concealed hinges - 125° opening
Links in aluminium.Pins in 430 stainless steel for 70-1-3639.
Pins in 304 Cu stainless steel for 70-1-3640.
Mounting features:
- For nested doors or surface mounted doors.
- LH or RH options.
- For horizontal or vertical applications.
Opening angle differs according to door thickness:
- 2 mm thickness: opening angle of 125°.
- 8 mm thickness: opening angle of 110°.
- 13 mm thickness: opening angle of 100°.
Please ask us for bespoke solutions.
Produced mainly in stainless steel, for a complete description of the materials contact us.
