Concealed system 2 axes articulation
It must consist of:
- (x1) Concealed corner hinges (62-1-3759)
- (x2) Concealed detachable hinges (62-1-3760)
- (x2) Cams (22-1-3562)
-(x2) Quarter turn (customer’s choice)
The cam was developed specifically for this application. It is compatible with a quarter turn of length 18 mm under flange and a training square of 8x8 mm by 4 mm long. The fixing will be done with a screw M6.
Provide a minimum clearance of 4.5 mm between the frame and the opening.
If necessary, consult us for more information and adaptation.
2 axes articulation - T Turn®
The invisible 2-axis articulation system (T-turn®) allows opening and closing along two axes.It must consist of:
- (x1) Concealed corner hinges (62-1-3759)
- (x2) Concealed detachable hinges (62-1-3760)
- (x2) Cams (22-1-3562)
-(x2) Quarter turn (customer’s choice)
The cam was developed specifically for this application. It is compatible with a quarter turn of length 18 mm under flange and a training square of 8x8 mm by 4 mm long. The fixing will be done with a screw M6.
Provide a minimum clearance of 4.5 mm between the frame and the opening.
If necessary, consult us for more information and adaptation.
